Battery Needle Penetration Testing Machine for Safety and Thermal Reaction Analysis

I. Product Overview:

This testing machine is designed to simulate the puncture scenario for batteries under controlled environmental conditions. Tests are conducted at a temperature of 20℃ ± 5℃. A battery equipped with a thermocouple (fixed on the large surface of the battery) is placed in a ventilated chamber, and a rust-free steel needle with a diameter of 2-8mm penetrates the center of the battery’s largest surface at a speed of 10-40mm/s. The needle remains in place for an arbitrary duration as per test requirements.

II. Compliance Standards:

MT/T1051

GB/T18332

GB/T8897.4

QC/T473/744

QC/T743

YD/B032

III. Technical Parameters:

Steel Needle	Diameter: φ3mm–φ8mm Length: 100mm (customizable). Material: High-temperature resistant steel.
Needle Stroke	Options: 200mm or 300mm.
Battery Clamping Distance	200mm
Unit Conversion	Kg, N, LB
Needle Penetration Speed	Range: 10–40mm/s (customizable).
Needle Force Range	1–20KN (optional)
Force Display	Options: LCD screen or touch screen display.
Force Measurement Accuracy	±1%
Drive Method	Pneumatic drive or hydraulic drive
Chamber Material	Inner chamber: Stainless steel Outer chamber: Cold-rolled steel, powder-coated finish
Special Features	Rear exhaust vent and pressure relief system Internal lighting system
Weight	Approximately 100kg
Power Supply	Single-phase, 220V, 50Hz
