Lab Film Coater Coating Machine for Coin Cell

Wechat:17720812054

Whatsapp:+86 13174506016

Email:David@batterymaking.com


  • Item NO.:

    TMAX-JK-TMJ-220A

  • Payment:

    L/C,T/T,Western Union, Paypal

  • Lead Time：

    5 days

  • Certificate:

    CE ROHS Certificate
Inquire Now
  • Product Detail

Lab Vacuum Film Applicator Coater Coating Machine With Vacuum Chuck & Doctor Blade



It has an unique driving system to produce smooth coating on all types of materials.

The flat vacuum chuck is built in to hold substrate sheet in place, which is particularly

useful when making thin coatings. One 150 mm width adjustable micrometer applicator

(doctorblade) and an oilless vacuum pump are included for immediate use.

Heating cover with digital temperature controller can dry films after coating up to 200°C

with a temperature accuracy of +/-1°C.

This equipment can be used for researches on ceramic tape castings and Li-Ion battery electrode coating.



ITEM

Data

Model

TMAX-JK-TMJ-220A

Working Voltage

220V ±10%  50Hz

Feed speed

0 ~ 100,the speed can be adjusted

Stroke Length

10 - 250 mm adjustable

Vacuum plate

With vacuum aluminum plate

Scraper range

0.02~0.5mm adjustable

Vacuum Pump

Yes

Max. Heating Temp.

200°C

Product Dimensions

500mm(L)×310mm(W)×330mm(H)

Heating drying system

At room temperature to 200 °C, temperature display

controller and accuracy + / - 1 °C

Net Weight

50 kg (135 lbs)

Warranty

One year warranty and lifetime maintenance

Film Applicator Coater
