Item NO.:
TMAX-YLJ20Payment:
L/C,T/T,Western Union, PaypalProduct Origin:
ChinaShipping Port:
XiamenLead Time：
5 daysCertificate:
CE ROHS Certificate
20L Barrel Material Pressing & Discharge Machine
I. Equipment Features
Application Scope
Pressing and discharging materials from barrels using extrusion method.
II. Main Equipment Parameters
1. Matching Container Parameters
l Inner Diameter: 35 cm
l Inner Depth: 30 cm
2. Structural Type
l Cantilever frame
3. Lifting Mechanism
l None
4. Pressing Method
l Double-acting hydraulic cylinder drives the pressing plate
5. Discharge Method
l Bottom discharge
6. Functional Parameters
l Plate Size: Matches 350mm barrel
l Unit Pressure: 10kg/cm²
l Total Pressure: 9T
l Motor Power: 1500 W
l Pump Flow: 6 L/min
l Cooling Method: Air-cooled hydraulic station
l Control Method: Foot switch for up/down
7. Barrel Locking
l Mechanical locking
8. Barrel Transfer
l Manual
9. Other Notes
l Total Power: ≤2000 W
l Weight: Approx. 350kg
l Floor Load: 1000kg/m²
l Dimensions: L1000mm × W700mm × H1526mm
l Color: Off-white
III. Spare & Wear Parts List
|
No. |
Name |
Specification |
Material |
Qty |
Remarks |
|
1 |
O-ring |
ΦD×ΦN |
Silicone |
1 |
Matching model, as per supplier standard |
IV. Supporting Conditions
|
No. |
Item |
Standard Requirements |
|
1 |
Workshop Height |
>2.5M |
|
2 |
Door Size |
Height >2.0M; Width >1.5M |
|
3 |
Installation Space |
Layout per general plan |
|
4 |
Others |
No corrosive, explosive gas or liquid |
