Item NO.:
TMAX-JRZX150Payment:
L/C,T/T,Western Union, PaypalLead Time：
5 daysCertificate:
CE ROHS CertificateLab-Scale Tab Forming Machine for Pouch Cell Assembly
Application
The Pouch Cell Tab Shaping Forming Machine is specialized equipment designed for thermal pressing and reshaping of tabs on stacked battery cells post-cutting. It ensures tabs have flat, uniform surfaces to facilitate subsequent manufacturing steps.
Key Features
- Integrates HIWIN linear guide rails, which guarantee precise guidance and even pressure application between upper and lower dies. - Boasts straightforward operation, high efficiency, stable temperature control, and superior consistency in output. - Utilizes pneumatic power to drive mold movement, with fixtures aiding in tab alignment and pressing. - Comes with a cell positioning tray for accurate placement of battery cells during operation. - Features a compact, dependable design that prioritizes user-friendliness. - Allows adjustment of pressing speed and forming duration to achieve optimal process control.
Technical Specifications
|
Parameter |
Specification |
|
Applicable Cell Size |
Up to 150 × 150 mm |
|
Die Hardness |
≥ HRC58 |
|
Die Lifetime |
3 million cycles (before regrinding) |
|
Press Plate Material |
Imported S136 SS, non deformable,
corrosion-resistant |
|
Forming Temperature |
Room temperature to 250 °C |
|
Distance Between Plates |
> 50 mm |
|
Operation Speed |
Up to 600 cycles/hour (air press) |
|
Air Source Requirement |
0.5–0.7 MPa |
|
Dimensions |
L230 × W200 × H250 mm |
|
Weight |
27 kg |
