Laboratory Electrode Stacking Machine For Pouch Cell Production Line

Wechat:17720812054

Skype and Whatsapp:+8617720812054

Email:Beata@batterymaking.com


  • Item NO.:

    TMAX-JK200
  • Payment:

    L/C,T/T,Western Union, Paypal
  • Lead Time:

    In stock
  • Certificate:

    CE ROHS Certificate
  • Product Detail

Laboratory Electrode Stacking Machine For Pouch Cell Production Line


1 TMAX-JK200 Battery stacking machine is a semi-automatic stacking machine. It is an ideal tool for stacking multiple layers of positive & negative electrode and separator for pouch cell.
2 The battery stacking machine is used for lithium battery stacking process, put the cathode, anode electrode and battery separator Z shaped lamination.

Model

Battery Stacking Machine TMAX-JK200

Voltage supply

AC 110v-220V Customized by requirements, 50HZ±10%

Power

100W

Warranty

One Year limited warranty with lifetime support

Stacking Layer Length

L(0-200)mm, W(0-200)mm

Max separator feeding diameter

Φ250mm

Fixed travel distance

400mm

Travel cycle

1 - 9999 cycles

Air supply

0.25-0.55MPa (40 - 80 psi)

Machine dimension(L*W*H)

650*400*700mm

Controller dimension(L*W*H)

200*300*380mm

Weight

40kg

Package size for stacking machine

660*740*430mm

Package size for control box

470*330*520mm

Stacking Machine




Pouch cell assembly
