Automatic Pouch Cell Lithium Battery Electrode Die Cutting Machine

Wechat:17720812054

Whatsapp:+86 13174506016

Email:David@batterymaking.com


  • Item NO.:

    TMAX-A-006
  • Payment:

    L/C,T/T,Western Union, Paypal
  • Product Origin:

    China
  • Shipping Port:

    Xiamen
  • Lead Time:

    5 days
  • Certificate:

    CE ROHS Certificate
  • Product Detail

Automatic Pouch Cell Lithium Battery Electrode Die Cutting Machine



Functions
 This equipment is suitable for lithium ion battery gap coating, separated rolling she atically stacked in the feed box;

Highlights
 Adopts frequency conversion motor automatically put volume, and with functions of rectification
 Floating roller tension closed-loop control material, and storage of material function
 High precision color optical testing positioning, fixed-length feeding servo for roller, and strip anti-skid functions
 Sheet piece by cutting mold and sheet mold blanking forming at one time
 Dual manipulator auto stacked sheet piece into the slot
 Timely according to the height of laminated manger
 Capacity: 25 to 40 times/min
 Die adopts aviation aluminum alloy, reducing mold weight, decreasing mold impact
 Adopt independent fixed feeding roller compaction, tear open outfit and convenient maintenance

Technical Parameters

ITEM

HBCQJ-200

HBCQJ-350

HBCQJ-450

Measure

1950*1350*1950mm

2200*1700*1950mm

2200*2200*1950mm

weight

About 1.5T

About 2.2T

About 2.8T

rate

3.5KW

3.5KW

4KW

power

AC220V/50HZ

AC220V/50HZ

AC220V/50HZ

Air source

0.6Mpa,260L/s

0.6Mpa,300L/s

0.6Mpa,350L/s

Vacuum source

-0.09Mpa,10L/Min

-0.09Mpa,10L/Min

-0.09Mpa,10L/Min

Applicable range

Length 90-350 width 40-200mm

Length 100-350 width 60-350mm

Length 100-350 width 80-450mm

Equipment capacity

20-40times/Min

20-40times/Min

15-35times/Min

Equipment optimal rate

98%

98%

98%

Burr precision

0.019mm

0.019mm

0.019mm

Mould life

Above 300 million times

Above 300 million times

Above 300 million times



Electrode Die Cutting Machine
